Dimensions（Length×Width×Height） (mm)

8530×2550×3000,3200(up to AC)

Maximum Manufacturer's Total Mass (kg)

12500

Maximum Manufacturer's Total Passenger(person)

69/64

Complete Vehicle Curb Weight(kg)

8000;8300

Seating Capacity (Number)

17-28

Height of Floor（mm）

850

First Step Height of Front, Middle Door( mm)

360

Front Overhang/Rear Overhang( mm)

2000/1530

Wheel Base(mm)

5000

Approach Angle/Departure Angle( °)

11/16

Maximum Gradability ( %)

≥15

Minimum Diameter of Turning Circle(m)

≤20

Maximum Speed(km/h)

69
