Dimensions（Length×Width×Height） (mm)

12000 ×2550×3680mm（lay down the trolley pole, up to the top）

Maximum Manufacturer's Total Mass (kg)

18000

Maximum Manufacturer's Total Passenger(person)

84

Complete Vehicle Curb Weight(kg)

12500

Seating Capacity (Number)

27+1

Standing Area

≥8㎡

Height of Floor（mm）

400

First Step Height of Front, Middle Door( mm)

400

Front Overhang/Rear Overhang( mm)

2860/2990

Wheel Base(mm)

6150

Approach Angle/Departure Angle( °)

7.5/7.5

Maximum Clear Opening Width of Door，Front/Rear( mm)

650/1100

Maximum Gradability ( %)

≥18

Minimum Diameter of Turning Circle(m)

≤24

Maximum Speed(km/h)

80
